The Xilinx Zynq-7000 ZC702 development board with the USB-to-JTAG module highlighted. This tutorial is designed for people running a Ubuntu client using VMware on a Windows host. Install Diligent JTAG Drivers On Windows You will need the cable drivers on both Windows and Ubuntu (you need them on Windows so that you can do a USB pass through to the virtual machine). Download and install either Vivado Design Suite (large!) or Vivado Lab Edition (smaller install size) from on Windows. This should install the Diligent JTAG drivers. Once the drivers have been installed on Windows, VMware detects the cable as “Future Devices Digilent Adept USB Device”, under VM->Removable Devices. Connect this device to the virtual machine.

Digilent USB Jtag Cable driver is a windows driver. As there are many drivers having the same name, we suggest you to try the Driver Tool, otherwise you can try.

Plug the micro USB cable into the ZC702 dev. Board and your computer.

On recent versions of Mac OS (as of Aug 2017), it looks like the JTAG device on the ZC-702 is recognized as a “Digilent Adept USB Device” without the installation of any additional drivers. Install Diligent JTAG Drivers And SDK On Ubuntu Download and install the SDK on Ubuntu (again, from ). This includes the xsdb program, which is located Now download and install Vivado Design Suite or Vivado Lab Edition on Ubuntu. Vivado includes the drivers for the JTAG cable, but unlike Windows, they are NOT automatically installed on Linux. To install the drivers on Linux, once Vivado is installed (we assume it’s been installed to /opt/Xilinx/), navigate to.

System: Linux: CentOS 6.5 Kernel: Linux localhost.localdomain 2.6.32-431.1.2.0.1.el6.x86_64 #1 SMP Fri Dec 13 13:06:13 UTC 2013 x86_64 x86_64 x86_64 GNU/Linux I selected 'Install Cable Drivers' as seen below. In the install error log (/opt/Xilinx/Vivado/2013.3/.xinstall/install.log) I am seeing the following message. --Install log = /opt/Xilinx/Vivado/2013.3/data/xicom/cable_drivers/lin64/install_script/install_drivers/install_drivers --Installing cable drivers.

--Driver versions in this package: windrvr=1301, xpc4drvr=1041 --Script name = /opt/Xilinx/Vivado/2013.3/data/xicom/cable_drivers/lin64/install_script/install_drivers/install_drivers --HostName = localhost.localdomain --Current working dir = /home/logic/Downloads/Xilinx_Vivado_SDK_2013.3_1017_1 --Script location = /home/logic/Downloads/Xilinx_Vivado_SDK_2013.3_1017_1 --Script argument=/opt/Xilinx/Vivado/2013.3/. Digilent Cable Drivers Installer error: FTDI Driver installer not found in ftdi.drivers_1.0.4-x86_64 --Kernel version = 2.6.32-431.1.2.0.1.el6.x86_64.

Un film puternic atat prin mesaj cat si prin sentimentele transmise. Un film cutremurator, un film care iti rascoleste toata fiinta atat prin povestea incredibila (dar adevarata), cat si prin imaginile socante prezentate. O capodopera pentru cinematografie semnata de genialul Roman Polanski si un rol magnific facut de Adrien Brody, un evreu in vremea holocaustului, un pianist macinat de muzica iubita pe tot parcusul filmului in incercarea disperata de supravietuire, un om care ajunge sa cunosca toata mizeria sufletului uman, ca in final sa se regaseasca acolo unde intotdeauna i-a fost locul. Possession 2002 pasiune film subtitrat 1.

--Arch = x86_64. --Installer version = 1100 --Unsetting ARCH environment variable. --File /lib/modules/misc/install_windrvr6 does not exist. --Installing USB drivers------------------------------------------ --Using udev. --File /usr/share/xusbdfwu.hex does not exist. --File version of /usr/share/xusbdfwu.hex = 0000.

--Updating xusbdfwu.hex file. --File /usr/share/xusb_xlp.hex does not exist. --File version of /usr/share/xusb_xlp.hex = 0000. Has anyone seen this issue before? It would be helpful for Xilinx to look into why things are failing, especially if Xilinx wants to push Linux on the Zynq 7000 devices. I think an important distinction may have been lost here, between: • Linux version running on a host development system (where the USB JTAG cable driver would be running) • Linux running on a target (e.g.

Zynq 7000) device These are entirely different and separate sets of contexts, needs, and requirements. This aside, dyessgg's main point seems valid. Inconsequential distinctions should not be used as a blanket excuse or fig leaf for witholding meaningful user support. -- Bob Elkind.

SIGNATURE: README for newbies is here: Summary: 1. Read the manual or user guide. Have you read the manual? Can you find the manual? Search the forums (and search the web) for similar topics. Do not post the same question on multiple forums.
